| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Frequency | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Cosel PJA600F-12 is an enclosed AC/DC power supply designed for reliable operation in demanding environments. It provides a stable 12V output with a maximum wattage of 600W and a current rating of 50A.
This converter features a universal input voltage range of 85-264 VAC, making it suitable for global applications. It operates efficiently, with typical efficiencies reaching up to 85% at 230V input. The operating temperature range is -20°C to 70°C, with derating required at higher temperatures.
Designed for chassis mounting, the PJA600F-12 meets various safety and compliance standards, including UL62368-1, EN62368-1, and EMI compliance with FCC-B and CISPR22-B. It also includes features like harmonic attenuation and SEMI F-47 compliance.
Key specifications include a line regulation of 240mV maximum and a load regulation of 600mV maximum. The dimensions are 214.9mm x 119.9mm x 61.0mm.
The output voltage is 12V and the output current is 50A, providing 600W of power.
The input voltage range is 85-264 VAC.
The operating temperature range is -20°C to +70°C with derating.
It has UL62368-1, C-UL (CSA62368-1), EN62368-1, and UL508 safety approvals.
Typical efficiency is 82% at 100VAC and 115VAC, and 85% at 230VAC.
The dimensions are 214.9mm (length) x 119.9mm (width) x 61.0mm (height).
