The Delta Electronics PJ-48V50WBNA is an AC/DC converter designed for commercial ITE applications. It delivers a 50W output power with a nominal voltage of 48V and a current rating of 1.1A.
Key electrical specifications include an input voltage range of 85 to 264 VAC and an efficiency of 85%. The converter features adjustable output, Power Factor Correction (PFC), and a universal input capability. It provides 3 kV of isolation voltage.
Mechanically, the PJ-48V50WBNA is an open frame, conformal coated unit designed for chassis mounting. Its dimensions are 132.0mm x 50.0mm x 26.6mm. The operating temperature range is -10°C to 70°C with derating.
This model is approved by agencies including CB, CE, cURus, and TUV, indicating compliance with various international safety standards. It is suitable for commercial ITE applications.
The output voltage is 48V.
The maximum output current is 1.1A.
The power rating is 50W.
The efficiency is 85%.
The operating temperature range is -10°C to 70°C (with derating).
The dimensions are 132.0mm x 50.0mm x 26.6mm.
It is approved by CB, CE, cURus, and TUV.
