PI4MSD5V9540BZEEX The PI4MSD5V9540BZEEX is a 2:1 multiplexer IC from Diodes Incorporated. It operates from 1.65V to 5.5V with a typical supply current of 65 µA and features 70 Ohm on-resistance.
Mfr Part #:

PI4MSD5V9540BZEEX

Available from 1 distributors
Mfr Name: Diodes Incorporated
Diodes Incorporated
The PI4MSD5V9540BZEEX is a 2:1 multiplexer IC from Diodes Incorporated. It operates from 1.65V to 5.5V with a typical supply current of 65 µA and features 70 Ohm on-resistance.
✓ Total Stock: 19,500 pcs
$ Price Range: $1.27

PI4MSD5V9540BZEEX Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
19,500 pcs
On Request
19500 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PI4MSD5V9540BZEEX Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Circuit
Clock Frequency
Independent Circuits
Mounting Type
Operating Temperature
Power Dissipation
Supplier Device Package
Supplier Package
Type
Voltage
Voltage Supply Source
View Similar Products (0)

PI4MSD5V9540BZEEX Description

Short technical summary and product information.

The PI4MSD5V9540BZEEX is a 2:1 multiplexer IC designed for signal switching applications. It supports a wide operating voltage range from 1.65V to 5.5V, making it suitable for various logic levels. The device offers a typical on-resistance of 70 Ohms and a propagation delay of 0.3 ns.



Electrical characteristics include a maximum supply current of 100 µA and a typical quiescent current of 65 µA. The multiplexer can handle clock frequencies up to 400 kHz and provides ESD protection of 8 kV HBM and 1 kV CDM. Latch-up performance exceeds 100 mA.



The IC is housed in an 8-WFDFN exposed pad package (8-TDFN 2x3 mm) with surface mount mounting. Operating temperature range is -40°C to 85°C. Power dissipation is rated at 100 mW.

PI4MSD5V9540BZEEX Quick Information

Subcategory: 2:1 Multiplexer

PI4MSD5V9540BZEEX Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PI4MSD5V9540BZEEX Estimated Pricing

Qty Low High
1+ $1.27 $1.27

Estimated market price range - modelled values for guidance only, not live distributor offers.

PI4MSD5V9540BZEEX Features

  • Wide operating voltage range 1.65V to 5.5V.
  • Low on-resistance of 70 Ohms maximum.
  • Fast propagation delay of 0.3 ns.
  • Low supply current: 65 µA typical.
  • ESD protection up to 8 kV HBM.

PI4MSD5V9540BZEEX Applications

  • Ideal for I2C bus multiplexing applications.
  • Used in mixed-voltage signal routing.
  • Suitable for portable battery-powered devices.
  • Applicable in industrial control systems.

PI4MSD5V9540BZEEX FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the PI4MSD5V9540BZEEX?

1.65V to 5.5V.

What is the operating temperature range?

-40°C to 85°C.

What is the package type?

8-WFDFN Exposed Pad (8-TDFN 2x3 mm).

What is the typical on-resistance?

70 Ohms maximum.

What is the propagation delay?

0.3 ns.

What is the maximum clock frequency?

400 kHz.

What is the ESD protection rating?

8 kV HBM and 1 kV CDM.
