PHE450SB5100JR06

The KEMET PHE450SB5100JR06 is a 10000 pF (10 nF) polypropylene film capacitor with a tolerance of ±5% and a rated voltage of 2000 VDC (2 kV). It features a double metallized polypropylene film dielectric and is encapsulated in a self-extinguishing resin box meeting UL 94 V-0. The capacitor is designed for through-hole mounting with PC pin terminations and a lead spacing of 15.00 mm. It has a compact body measuring 18.00 mm x 6.50 mm x 12.50 mm. The operating temperature range is -55°C to 105°C, making it suitable for a wide variety of environments. This capacitor is intended for high frequency applications with high current stress, such as deflection circuits in televisions and protection circuits in switched-mode power supplies (SMPS) and electronic ballasts. It is also used for pulse and DC transient suppression. Note: The PHE450 series has been replaced by the KEMET R76 series; this part is not recommended for new designs.
