| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
56 pcs
|
56 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Control Features | |
| Cooling | |
| Current | |
| Features | |
| Height | |
| Isolation Resistance | |
| Length | |
| Line Regulation | |
| Load Regulation | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage Adjustment Range | |
| Over Voltage Protection | |
| Overload Protection | |
| Power (Watts) | |
| Remote On/Off | |
| Ripple & Noise | |
| Safety Agency Certifications | |
| Storage Temperature | |
| Temperature Coefficient | |
| Thermal Protection | |
| Type | |
| Voltage | |
| Voltage - Input (Max) | |
| Voltage - Isolation (Minimum @ Input to Baseplate) | |
| Voltage - Isolation (Minimum @ Input to Output) | |
| Voltage - Output 1 | |
| Warranty | |
| Width |
The TDK-Lambda PH50S280-28 is an isolated DC-DC converter module from the PH-S series. It provides a single regulated output of 28V at up to 1.8A, delivering 50W of power. The converter accepts a wide input voltage range of 200V to 400V DC, making it suitable for high-voltage bus applications in industrial and commercial equipment.
Key electrical specifications include line regulation of 0.4% or 20mV and load regulation of 0.8% or 40mV. Ripple and noise are limited to 280mV pk-pk. The module includes protection features such as overcurrent (105-140% with auto recovery), overvoltage (125-145%), and overtemperature protection with internal sensing and self-resetting. Remote on/off control is provided (active low).
The converter is housed in a through-hole module package measuring 86.0mm x 41.0mm x 12.7mm. It is designed for conduction or forced air cooling. The operating baseplate temperature range is -20°C to +85°C. Safety certifications include UL60950-1, CSA60950-1, EN60950-1, and CE Mark. The product is RoHS3 compliant and has an MSL of 1 (unlimited).
200V to 400V DC.
28V at 1.8A (50W).
-20°C to +85°C baseplate temperature.
Yes, RoHS3 compliant.
Overcurrent protection (105-140% auto recovery), overvoltage protection (125-145%), and overtemperature protection (self-resetting).
3000VAC input to output, 2500VAC input to baseplate.
Through-hole module.
