| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,146 pcs
|
1146 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The PH1RB-04-UA from Adam Technologies Inc is a 4-position unshrouded male pin header designed for board-to-board connections. It features a single row of square brass contacts with gold flash finish, offering reliable electrical performance. The connector has a pitch of 2.54mm (0.100") and is mounted via through hole, right angle configuration, making it suitable for perpendicular board mounting.
Rated at 3A current and 250VAC, the header operates over a temperature range of -40°C to 105°C. The insulation is made of glass-filled PBT (UL94 V-0) in black color, providing good mechanical strength and flame retardancy. The contact length is 5.97mm, and the insulation height is 2.50mm.
This header is ideal for applications requiring a compact, low-profile interconnect solution. Its push-pull fastening type and unshrouded design allow for easy mating and unmating.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.16 | $0.16 |
| 10+ | $0.14 | $0.14 |
| 100+ | $0.12 | $0.12 |
| 500+ | $0.11 | $0.11 |
| 1,000+ | $0.10 | $0.10 |
| 5,000+ | $0.09 | $0.09 |
| 10,000+ | $0.09 | $0.09 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4 positions.
2.54mm (0.100").
3A.
250VAC.
Through hole, right angle.
-40°C to 105°C.
Gold flash.
