| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Auxiliary Bias Supply | |
| Control Features | |
| Cooling | |
| Current | |
| Features | |
| Height | |
| Isolation Voltage (Input to Baseplate) | |
| Isolation Voltage (Input to Output) | |
| Length | |
| Line Regulation | |
| Load Regulation | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage Adjustment Range | |
| Over Voltage Protection | |
| Overload Protection | |
| Parallel Operation | |
| Power (Watts) | |
| Remote On/Off Logic | |
| Remote Sensing | |
| Safety Agency Approvals | |
| Storage Temperature | |
| Temperature Coefficient | |
| Thermal Protection | |
| Type | |
| Voltage | |
| Voltage - Input (Max) | |
| Voltage - Output 1 | |
| Warranty | |
| Width |
The TDK-Lambda PH150F48-15 is a high-density isolated DC-DC converter module from the PH-F series. It accepts a nominal 48V input (36-76V range) and provides a regulated 15V output at up to 10A, delivering 150W of output power. The module includes remote on/off control (active low), remote sensing, and parallel operation capability with current sharing.
Protection features include overvoltage protection (150-180% of output), overload protection (105-140% with automatic recovery), and thermal protection with internal sensing and self-resetting. The converter offers line regulation of 0.4% or 20mV and load regulation of 0.8% or 40mV, whichever is greater. The output voltage can be adjusted from 6V to 18V.
The module is housed in a through-hole package measuring 86.0mm x 83.0mm x 12.7mm and is designed for conduction or forced air cooling. It is suitable for ITE (commercial) applications and carries safety approvals including UL60950-1, CSA60950-1, EN60950-1, and CE Mark.
The input voltage range is 36V to 76V DC (nominal 48V).
It provides a single output of 15V at up to 10A, delivering 150W.
The baseplate operating temperature range is -20°C to +85°C.
The part is listed as RoHS3 Compliant, but this status is unverified and should be confirmed with the manufacturer.
It includes overvoltage protection (150-180%), overload protection (105-140% with automatic recovery), and thermal protection with internal sensing and self-resetting.
Yes, parallel operation is supported using the current share pin (PC) with sharing within 5%.
Input to output isolation is 3000VAC, and input to baseplate isolation is 2500VAC.
