The TDK Corporation PFH500F-48-0D0-R is a 504W AC-DC power module designed for applications where convection or forced air cooling is not viable. It features a compact 4" x 2.4" footprint and a full brick package, suitable for PCB mounting.
This module delivers a regulated 48V DC output at up to 10.5A, with an adjustable output voltage capability. It operates from a wide AC input range of 85V to 265V and boasts a high efficiency of 91%. The baseplate can withstand high ambient temperatures up to 100°C, making it ideal for outdoor enclosures or liquid-cooled applications.
Key features include a PMBus interface for remote monitoring and programming, optional droop mode load sharing, and I²C communication. The module is designed for ITE (Commercial) applications and meets standards such as 60950-1 and 62368-1.
The nominal output voltage is 48V DC.
The maximum output current is 10.5A.
The input voltage range is 85V AC to 265V AC.
The power rating is 504W.
The operating temperature range is -40°C to 100°C with derating.
Yes, it offers optional droop mode load sharing.
It features a PMBus interface and I2C communication for remote monitoring and programming.
