PFE500S-48/T The PFE500S-48/T is a 500W enclosed AC/DC converter from TDK Corporation, providing a single 48V output at 10.5A. It features universal input (85-265VAC) and 86% efficiency.
Mfr Part #:

PFE500S-48/T

Mfr Name: TDK Corporation
TDK Corporation
The PFE500S-48/T is a 500W enclosed AC/DC converter from TDK Corporation, providing a single 48V output at 10.5A. It features universal input (85-265VAC) and 86% efficiency.
Stock on Request

PFE500S-48/T Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Current
Efficiency
Features
Height
Length
Mounting Type
Number of Outputs
Operating Temperature
Power (Watts)
Power Rating
SVHC Present
Standard Number
Type
Voltage
Width

PFE500S-48/T Description

Short technical summary and product information.

The TDK PFE500S-48/T is an enclosed AC/DC converter designed for commercial ITE applications. It delivers a single output of 48V at 10.5A, with a maximum power rating of 500W (504W peak). The converter operates from a universal AC input of 85 to 265 VAC, providing flexibility for global use. With an efficiency of 86%, it reduces power loss and heat generation. The operating temperature range is -40°C to 100°C with derating, allowing use in demanding environments. The converter is housed in a full brick package (11-DIP Module, Full Brick) with through-hole mounting, measuring 122.0mm x 70.0mm x 12.7mm and weighing 300.28g. It is approved to CE and cULus safety standards per UL 60950-1. The device is RoHS compliant and lead-free.

PFE500S-48/T Quick Information

Product Type: AC/DC Converter
Series: PFE500S
Canonical Name: TDK Corporation PFE500S-48/T AC/DC Converter
Subcategory: Enclosed

PFE500S-48/T Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PFE500S-48/T Features

  • Universal AC input range 85 to 265 VAC.
  • Single 48V output at 10.5A, 500W power.
  • 86% efficiency reduces thermal dissipation.
  • Enclosed full brick DIP-11 module.
  • Operating temperature -40°C to 100°C.

PFE500S-48/T Applications

  • Designed for commercial ITE equipment.
  • Suitable for industrial power supplies.
  • Ideal for distributed power architectures.

PFE500S-48/T FAQs

7 frequently asked questions generated from this part’s specifications.
What is the output voltage of the PFE500S-48/T?

48V.

What package is the PFE500S-48/T available in?

11-DIP Module, Full Brick.

What is the operating temperature range?

-40°C to 100°C with derating.

What is the input voltage range?

85 to 265 VAC.

What is the efficiency of the converter?

86%.

What mounting type does the PFE500S-48/T use?

Through Hole.

What are the dimensions of the module?

122.0mm x 70.0mm x 12.7mm (length x width x height).
