| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The TDK Corporation PFE500S-12 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It provides a 500W output power with a single 12V output.
The converter accepts a wide input voltage range of 85 to 265 VAC and delivers a current of 33A. It features universal input and an efficiency of 82%. The operating temperature range is from -40°C to 100°C with derating.
This unit is mounted via through-hole and comes in a 11-DIP Module, Full Brick package. It adheres to the standard number 60950-1 and has approval from CE and cULus agencies. The dimensions are 116.8mm in length, 61.0mm in width, and 12.7mm in height.
Environmental compliance includes RoHS3 compliance, Moisture Sensitivity Level 1, and REACH unaffected status. This converter is suitable for various commercial applications requiring a reliable power supply.
The PFE500S-12 provides a 12V output.
The output current is 33A.
The input voltage range is 85 to 265 VAC.
The operating temperature is -40°C to 100°C with derating.
It is in a 11-DIP Module, Full Brick package.
It is mounted through hole.
