| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,183 pcs
|
1183 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Attachment Method | |
| Fin Height | |
| Length | |
| Material | |
| Material Finish | |
| Mounting Type | |
| Package Cooled | |
| Shape | |
| Thermal Resistance | |
| Type | |
| Width |
This Aavid, Thermal Division of Boyd Corporation PF750G heat sink is engineered for effective thermal management of TO-220 packaged electronic components. Constructed from aluminum, it provides a balance of thermal performance and weight.
The heat sink features a fin height of 19.00mm and dimensions of 11mm width by 22mm length, offering a substantial surface area for heat dissipation. Its thermal resistance is rated at 20.3K/W, making it suitable for applications requiring efficient cooling.
Designed for board-level applications, the PF750G utilizes a vertical mounting style with PCB through-hole termination. The material finish is tin, and it is secured using a clip and PC pin attachment method. This heat sink is part of the Aavid Thermalloy product line, known for its thermal solutions.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The thermal resistance of the PF750G heat sink is 20.3K/W.
The PF750G heat sink is designed for the TO-220 package type.
The PF750G heat sink has dimensions of 11mm width, 22mm length, and a fin height of 19.00mm.
The PF750G heat sink is constructed from aluminum.
The PF750G heat sink is mounted using PCB through-hole.
