| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
18,000 pcs
|
18000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Fastening Type | |
| Halogen Free | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Style | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Package Quantity | |
| Packaging Type | |
| Pitch (@ Power) | |
| Pitch (@ Signal) | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating | |
| current_rating (Maximum @ Per power blade, one pin powered) | |
| current_rating (Maximum @ Per signal pin, 4 pins powered) |
The Samtec PETC-02-12-02-01-L-VT is a signal/power combo header from the PowerStrip/40 series. It features 12 signal pins at 2.54 mm pitch and 2 power blades at 6.35 mm pitch, arranged in 4 rows. The insulator is black liquid crystal polymer (LCP) and contacts are copper alloy with gold plating on the contact area and matte tin on tails. The header is shrouded with a friction lock for secure mating and has a through hole solder termination. Operating temperature range is -55°C to 125°C. Current rating is 50 A per power blade and 4.8 A per signal pin, with a voltage rating of 450 VAC / 636 VDC. The component is packaged in trays of 32 pieces.
| Qty | Low | High |
|---|---|---|
| 1+ | $14.89 | $14.89 |
| 10+ | $13.43 | $13.43 |
| 25+ | $11.96 | $11.96 |
| 50+ | $9.84 | $9.84 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
14 positions: 12 signal pins and 2 power blades.
Signal contacts: 2.54 mm (0.100"), power contacts: 6.35 mm (0.250").
Power blade: 50 A maximum (per blade, one pin powered). Signal pin: 4.8 A maximum (4 pins powered).
450 VAC / 636 VDC maximum.
Through hole with solder termination.
-55°C to 125°C.
Gold on contact area (10 µ") and matte tin on tail.
