| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,895 pcs
|
2895 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Frequency | |
| Mounting Type | |
| Number of Mixers | |
| RF Type | |
| Secondary Attributes | |
| Storage Temperature | |
| Supplier Device Package | |
| Supplier Package | |
| Tape & Reel |
The pSemi PE4140B-Z is an ultra-high linearity passive broadband Quad MOSFET array designed for high dynamic range performance, capable of operation beyond 6.0 GHz. This device is manufactured on pSemi’s UltraCMOS™ process, a patented variation of silicon-on-insulator (SOI) technology.
This quad array operates with differential signals at all ports (RF, LO, IF), making it suitable for mixer applications such as frequency up/down-conversion and phase detection. It supports LO powers ranging from -7 dBm to +20 dBm. Typical applications include Cellular/PCS Base Stations, Wireless Broadband Communications, and STB/Cable modems.
The PE4140B-Z features ultimate Quad MOSFET array performance with ultra-high linearity and broadband capabilities. It offers low conversion loss and high LO isolation. The component is packaged in a small 6-lead 3x3 mm DFN package and is designed for surface mount applications.
Key electrical specifications include a typical Drain-Source 'ON' Resistance of 7.75 Ω and a typical Drain-Source Voltage Match of 12 mV. The operating frequency range is specified from DC to 6.0 GHz.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.77 | $5.77 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating frequency range is DC to 6.0 GHz.
The PE4140B-Z is supplied in a 6-lead DFN package.
The typical Drain-Source 'ON' Resistance is 7.75 Ω.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
