| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | 9905 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Output Type | |
| Power Dissipation | |
| Resolution | |
| Settling Time |
The PCM54HP from Burr-Brown Corp is a 16-bit monolithic digital-to-analog converter specifically engineered for digital audio applications. It utilizes ultra-stable nichrome thin-film resistors to ensure monotonicity, low distortion, and minimal differential linearity error over time and temperature.
Key features include a 16-bit resolution, 15-bit monotonicity (typical), and a total harmonic distortion of -92dB for the K Grade. The device boasts a dynamic range of 96dB and a fast settling time of 3μs for voltage output. It supports dual power supplies ranging from ±5V for the PCM55 to ±12V for the PCM54. The output can be configured as either ±3V voltage or ±1mA current.
Designed for ease of use, the PCM54HP includes an internal voltage reference and a low-noise operational amplifier on a single chip. A current output option is available, settling typically within 350ns to ±0.006% of FSR. The PCM54HP is available in a 28-pin DIP package, while the PCM55 variant comes in a 24-lead SOIC package. Power dissipation is typically less than 200mW with ±5V supplies.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.22 | $2.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The PCM54HP has a 16-bit resolution.
The PCM54HP has a typical monotonicity of 15-bit.
The total harmonic distortion for the K Grade of the PCM54HP is -92dB.
The settling time for the voltage output of the PCM54HP is 3μs.
The PCM54HP has a dynamic range of 96dB.
The PCM54HP offers a ±3V voltage output or a ±1mA current output.
The PCM54HP can operate on supply voltages ranging from ±5V to ±12V.
