The PCM4204PAPR by ADI Electronics is a high-performance, four-channel audio Analog-to-Digital Converter (ADC). It supports both 24-bit linear PCM and 1-bit Direct Stream Digital (DSD) output data formats, with PCM output sampling rates up to 216kHz.
Key performance metrics include a typical ADC SNR of 118dB and a THD+N of -105dB for PCM output. For DSD output, the dynamic range is 115dB with THD+N of -103dB. The device features a flexible audio serial port supporting master or slave mode operations with Left-Justified, Right-Justified, and I²S data formats. It also includes a digital high-pass filter for DC removal and a clipping flag output for each channel.
Designed for applications such as digital recorders, mixing desks, audio effects processors, broadcast studio equipment, surround sound encoders, and high-end A/V receivers, the PCM4204PAPR operates with analog supplies of +5V and digital supplies of +3.3V. It is housed in a thermally-enhanced HTQFP-64 package, suitable for surface mount applications.
Power dissipation varies with sampling rate, with typical values of 600mW at 48kHz, 640mW at 96kHz, and 615mW at 192kHz. A power-down mode is also available to conserve energy when not in use.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.17 | $5.17 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum sampling rate for PCM output is 216kHz.
The typical ADC SNR is 118dB for PCM output.
It supports DSD and PCM digital audio interfaces.
The operating temperature range is -10°C to 70°C.
It requires a +5V analog supply and a +3.3V digital supply.
It is supplied in a thermally-enhanced HTQFP-64 package.
