| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
153 pcs
|
153 pcs | On Request | 1 | On Request | On Request | 04/05+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Architecture | |
| Control Interface | |
| Operating Temperature Range | |
| Package / Case | |
| Resolution | |
| Sampling Frequency |
The PCM1754 from Texas Instruments is a stereo digital-to-analog converter (DAC) designed for audio applications. It employs an enhanced delta-sigma architecture, featuring 4th-order noise shaping and 8-level amplitude quantization for excellent dynamic performance and improved clock jitter tolerance.
This DAC supports 24-bit resolution and a sampling rate of up to 192 kHz, delivering high-fidelity audio output. Key performance metrics include a typical SNR of 106 dB and a THD+N of 0.002%. It provides 2 analog outputs and operates from a single 5V power supply.
The PCM1754 features hardware control and interfaces with industry-standard audio data formats, making it suitable for integration with audio DSP and decoder chips. It is available in a compact 16-lead SSOP package, designed for surface mounting.
With its robust performance and flexible interface, the PCM1754 is well-suited for home audio systems, portable audio devices, and other applications requiring high-quality digital-to-analog conversion.
The PCM1754 operates from a single 5V supply.
The PCM1754 is available in a 16-lead SSOP package (SSOP-16).
The PCM1754 operates from -40°C to 85°C.
The PCM1754 has 24-bit resolution.
The typical SNR is 106 dB.
The typical THD+N is 0.002%.
The PCM1754 has two DAC channels.
