PCA9555HF,118 The NXP Semiconductors PCA9555HF,118 is a 16-bit I2C/SMBus IO Expander. It features a 400 kHz clock frequency and operates within a 2.3V to 5.5V supply voltage range.
Mfr Part #:

PCA9555HF,118

Available from 1 distributors
Mfr Name: NXP Semiconductors
NXP Semiconductors
The NXP Semiconductors PCA9555HF,118 is a 16-bit I2C/SMBus IO Expander. It features a 400 kHz clock frequency and operates within a 2.3V to 5.5V supply voltage range.
✓ Total Stock: 1,000 pcs
$ Price Range: $1.15

PCA9555HF,118 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
1,000 pcs
On Request
1000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PCA9555HF,118 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Clock Frequency
Current
Features
Interface
Interrupt Output
Mounting Type
Number of I
Operating Temperature
Output Type
Supplier Device Package
Voltage
View Similar Products (0)

PCA9555HF,118 Description

Short technical summary and product information.

The PCA9555HF,118 from NXP Semiconductors is a 16-bit General Purpose parallel Input/Output (GPIO) expansion device designed for I2C-bus/SMBus applications. It offers higher drive capability, 5V I/O tolerance, and lower supply current compared to previous generations.



This I/O expander operates with a supply voltage range of 2.3V to 5.5V and supports a clock frequency of up to 400 kHz. It features 16 I/O pins that default to inputs, with individual I/O configuration options. The device includes a polarity inversion register and an active LOW interrupt output, which activates when an input state changes.



Packaged in a 24-HWQFN (4x4) with a surface mount type, the PCA9555HF,118 is suitable for various applications requiring additional I/O expansion, such as for ACPI power switches, sensors, push buttons, LEDs, and fans. The device also includes noise filtering on SCL/SDA inputs and has a power-on reset feature.

PCA9555HF,118 Quick Information

Product Type: IO Expander
Canonical Name: PCA9555HF,118 16-bit I2C/SMBus I/O Port with Interrupt
Subcategory: IO Expanders

PCA9555HF,118 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PCA9555HF,118 Estimated Pricing

Qty Low High
1+ $1.15 $1.15

Estimated market price range - modelled values for guidance only, not live distributor offers.

PCA9555HF,118 Features

  • 16-bit I2C/SMBus IO expansion.
  • Operates from 2.3V to 5.5V supply.
  • Supports 400 kHz clock frequency.
  • Features 5V tolerant I/Os.
  • Includes active LOW interrupt output.

PCA9555HF,118 Applications

  • Expands I/O for microcontrollers.
  • Interface for sensors and switches.
  • Control for LEDs and fans.
  • Suitable for ACPI power management.

PCA9555HF,118 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating voltage range for the PCA9555HF,118?

The PCA9555HF,118 operates within a supply voltage range of 2.3 V to 5.5 V.

What is the package type for the PCA9555HF,118?

The PCA9555HF,118 is available in a 24-WFQFN Exposed Pad package.

What is the operating temperature range of the PCA9555HF,118?

The operating temperature range for the PCA9555HF,118 is -40°C to 85°C.

Does the PCA9555HF,118 have an interrupt output?

Yes, the PCA9555HF,118 features an active LOW interrupt output.

What is the maximum clock frequency for the PCA9555HF,118?

The PCA9555HF,118 supports a maximum clock frequency of 400 kHz.
