PCA9536TK,118 The NXP Semiconductors PCA9536TK,118 is a 4-bit I2C/SMBus IO Expander. It operates from 2.3V to 5.5V and features 5V tolerant I/Os.
Mfr Part #:

PCA9536TK,118

Available from 3 distributors
Mfr Name: NXP Semiconductors
NXP Semiconductors
The NXP Semiconductors PCA9536TK,118 is a 4-bit I2C/SMBus IO Expander. It operates from 2.3V to 5.5V and features 5V tolerant I/Os.
✓ Total Stock: 416,948 pcs
$ Price Range: $1.15

PCA9536TK,118 Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Tomark Electronics Ltd ✓
Non-Authorised Inventory information
400,948 pcs
On Request
400948 pcs On Request 1 On Request On Request On Request On Request On Request
Risen Electronics ✓
Non-Authorised Inventory information
10,000 pcs
On Request
10000 pcs On Request 1 On Request On Request On Request On Request 2026-02-16 21:33:16
Fe Components ✓
Non-Authorised Inventory information
6,000 pcs
On Request
6000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PCA9536TK,118 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Clock Frequency
Current
ESD Protection
Features
Interface
Interrupt Output
Mounting Type
Number of I
Operating Temperature
Output Type
Supplier Device Package
Voltage
View Similar Products (0)

PCA9536TK,118 Description

Short technical summary and product information.

The PCA9536TK,118 from NXP Semiconductors is an 8-pin CMOS device providing 4 bits of General Purpose parallel Input/Output (GPIO) expansion for I2C-bus/SMBus applications. This IO expander is suitable for applications requiring additional I/O for components like ACPI power switches, sensors, push buttons, and LEDs.



Key features include a configurable 4-bit I/O port, an operating power supply voltage range of 2.3 V to 5.5 V, and 5 V tolerant I/Os. The device supports a clock frequency up to 400 kHz and includes a polarity inversion register for active HIGH or LOW operation. It defaults to 4 inputs with internal 100 kΩ pull-up resistors.



The PCA9536TK,118 is available in an 8-HVSON (3x3) package, designed for surface mount installation. It operates within a temperature range of -40°C to 85°C. The device also incorporates an internal power-on reset and noise filters on SCL/SDA inputs, ensuring reliable operation.



This IO expander is ideal for systems needing simple I/O expansion without complex interface requirements. Its fixed I2C-bus address allows for a single device on the bus, simplifying system design.

PCA9536TK,118 Quick Information

Product Type: IO Expander
Canonical Name: PCA9536TK,118 4-bit I2C-bus and SMBus I/O port
Subcategory: IO Expander

PCA9536TK,118 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PCA9536TK,118 Estimated Pricing

Qty Low High
1+ $1.15 $1.15

Estimated market price range - modelled values for guidance only, not live distributor offers.

PCA9536TK,118 Features

  • 4-bit I2C/SMBus GPIO expansion.
  • Operates from 2.3V to 5.5V supply.
  • 5V tolerant I/O pins.
  • 400 kHz maximum clock frequency.
  • Available in 8-HVSON package.

PCA9536TK,118 Applications

  • Extends I/O for microcontrollers.
  • Controls LEDs and sensors.
  • Used in embedded systems.
  • Simplifies interface designs.

PCA9536TK,118 FAQs

4 frequently asked questions generated from this part’s specifications.
What is the operating voltage range for the PCA9536TK,118?

The operating voltage range is 2.3V to 5.5V.

What package type is the PCA9536TK,118 supplied in?

The PCA9536TK,118 is supplied in an 8-HVSON (3x3) package.

What is the operating temperature range for this IO Expander?

The operating temperature range is -40°C to 85°C.

What is the RoHS status of the PCA9536TK,118?

The RoHS status is RoHS3 Compliant.
