The Cosel PCA1000F-15 is an enclosed AC/DC power supply designed for ITE (Commercial) and Medical applications. It offers a robust 1050W output power with a nominal voltage of 15V and a current rating of 70A.
Key electrical specifications include a universal input voltage range of 85-264 VAC and a DC input range of 88-370 VDC. The converter boasts high efficiency up to 92% and features like adjustable output, Power Factor Correction (PFC), remote on/off, and remote sense. It operates within a temperature range of -20°C to 70°C.
Mechanically, the unit measures 178.0mm x 102.0mm x 41.0mm, designed for chassis mounting. It meets safety standards including 60601-1, 60950-1, and 62368-1, and carries approvals from CE, CSA, cURus, D-Mark, and UL. The power supply also complies with FCC-B, CISPR32-B, and EN55032-B for EMI, and meets various EMS standards.
This model is suitable for applications requiring reliable power conversion with advanced features and safety certifications.
The output voltage is 15V.
The maximum output current is 70A.
The power rating is 1050W.
The efficiency is 92%.
The operating temperature range is -20°C to 70°C.
It complies with 60601-1, 60950-1, and 62368-1 standards.
Key features include adjustable output, PFC, remote ON/OFF, remote sense, and universal input.
