| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Halogen Free | |
| Industrial Grade | |
| Input Frequency | |
| Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| SVHC Present | |
| Type | |
| Voltage |
The Cosel PBW50F-5-N1 is an AC/DC converter designed for ITE (Commercial) applications. It features an open-frame construction suitable for chassis mounting.
This unit accepts a universal input voltage range of 85-264 VAC and delivers a stable -5V DC output with a maximum current of 4A. Key electrical specifications include an efficiency of 77% and line/load regulation of 20mV and 40mV respectively. The operating temperature range is -10°C to 71°C with derating.
Safety agency approvals include CE, cURus, and TUV. The converter also complies with harmonic attenuator standards (IEC61000-3-2) and EMI standards (FCC-B, CISPR22-B, EN55011-B, EN55022-B, VCCI-B). It offers overcurrent and overvoltage protection features.
Dimensions are 119.9mm x 31.0mm x 82.0mm.
-5V
4A
85-264 VAC
74%
-10°C to 71°C (With Derating)
Chassis Mount
