Mfr Part #:

PBC36DAAN

PBC36DAAN is a 72-position, 2.54mm pitch, through-hole male pin header from Sullins Connector Solutions. It features tin-plated phosphor bronze contacts and a black PBT insulator.

✓ Total Stock: 207 pcs

$ Price Range: $1.95 - $3.55

PBC36DAAN Available from 2 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Braun Electronic Components ✓ Non-Authorised Inventory information	195 pcs On Request	195 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Trace Tec ✓ Non-Authorised Inventory information	12 pcs On Request	12 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

PBC36DAAN Description

Short technical summary and product information.

The PBC36DAAN is a breakaway header from Sullins Connector Solutions, designed for board-to-board or cable connections. It has 72 positions arranged in two rows with a standard 2.54mm (0.100") pitch. The through-hole mounting with solder termination ensures reliable mechanical and electrical connections.

Key specifications include tin-plated phosphor bronze contacts with a 0.25µm thickness, a 3A current rating, and an operating temperature range of -65°C to 125°C. The insulator is made of black PBT (Polybutylene Terephthalate) with a UL94 V-0 flammability rating, suitable for high-temperature environments.

This unshrouded header uses a push-pull fastening type and is suitable for various applications requiring reliable interconnects. The square contact shape and 5.84mm mating contact length provide robust mating with female sockets.

PBC36DAAN Quick Information

Product Type: Header, Male Pins

Series: PBC

Canonical Name: PBC36DAAN — 72 Position, 2.54mm Pitch, Through Hole, Header, Male Pins

Subcategory: Male Pins

PBC36DAAN Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Yes

PBC36DAAN Estimated Pricing

Qty	Low	High
1+	$3.55	$3.55
50+	$2.69	$2.69
100+	$2.57	$2.57
500+	$2.29	$2.29
1,000+	$2.18	$2.18
5,000+	$1.95	$1.95

Estimated market price range - modelled values for guidance only, not live distributor offers.

PBC36DAAN Features

72 positions in a 2-row configuration.
2.54mm (0.100") pitch for standard spacing.
Through-hole mounting for secure soldering.
Tin-plated phosphor bronze contacts.
UL94 V-0 flammability rated insulator.

PBC36DAAN Applications

Ideal for board-to-board connections.
Suitable for cable-to-board applications.
Used in data communication equipment.
Common in industrial control systems.

PBC36DAAN FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does the PBC36DAAN have?

72 positions, all loaded.

What is the pitch of the PBC36DAAN?

2.54mm (0.100")

What is the current rating of the PBC36DAAN?

What is the mounting type of the PBC36DAAN?

Through-hole

What is the operating temperature range?

-65°C to 125°C

What is the insulation material and flammability rating?

Polybutylene Terephthalate (PBT) with UL94 V-0 rating.

What is the contact finish?

Tin with 0.25µm (10.0µin) thickness.

Category	Headers, Male Pins
Manufacturer Name	Sullins Connector Solutions
Connector Type	Header, Breakaway
Contact Finish	Tin
Contact Finish Thickness	10.0µin (0.25µm)
Contact Length	5.84mm (0.230")
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3A
Fastening Type	Push-Pull
Industrial Grade	Yes
Insulation Color	Black
Insulation Height	2.54mm (0.100")
Insulation Material	Polybutylene Terephthalate (PBT)
Lead Spacing	2.54 mm
Lead Style	Solder
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	72
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-65°C ~ 125°C
Overall Contact Length	0.450" (11.43mm)
Pitch	2.54mm (0.100")
Row Spacing	0.100" (2.54mm)
Shrouding	Unshrouded
Style	Board to Board or Cable
Tape & Reel	No
Termination	Solder
