The Cosel PBA75F-5 is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It offers a single 5V output with a maximum current of 15A, providing a total power of 75W. The unit accepts a universal input voltage range from 85 to 264 VAC, making it suitable for global use.
Key electrical specifications include an efficiency of 83% and various protection features such as overcurrent and overvoltage protection. The power supply is designed for chassis mounting and includes isolation voltages of 3kV (Input-Output), 2kV (Input-FG), and 500V (Output-FG).
Operating within a temperature range of -10°C to 71°C (with derating), the PBA75F-5 is built for reliable performance. It complies with safety agency approvals including CE, cURus, and TUV. The dimensions are 5.31" L x 1.26" W x 3.23" H.
AC 85-264VAC or DC 110-370VDC.
5V at 15A (75W).
-10°C to 71°C with derating.
Overcurrent protection (works over 105% of rated current, auto recovery) and overvoltage protection (5.75-7.00V).
Input-output 3kV AC, input-FG 2kV AC, output-FG 500V AC.
Chassis mount, enclosed.
83% typical at both 100V and 200V AC input.
