The Cosel PBA15F-3R3-N is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It provides a single output of 3.3V at up to 3A, delivering a maximum wattage of 9.9W.
This converter features a universal input voltage range of 85-264 VAC or 110-370 VDC, making it suitable for global use. It is designed for chassis mounting and has an efficiency of 68% typical.
Key electrical specifications include a line regulation of 20mV maximum and a load regulation of 40mV maximum. The operating temperature range is -10°C to 71°C with derating. Safety approvals include CE, cURus, and TUV, and it complies with various standards such as IEC61000-3-2 for harmonic attenuation and FCC-B, CISPR22-B for EMI.
Dimensions are 85.1mm in length, 31.0mm in width, and 78.0mm in height.
85-264 VAC or 110-370 VDC.
-10°C to 71°C with derating.
Enclosed chassis mount package.
Yes, works over 105% of rated current with automatic recovery.
3000 VAC for 1 minute.
UL60950-1, C-UL(CSA60950-1), EN62368-1, UL508 (with cover), CE, cURus, TUV.
74% typical at both 100V and 200V AC input under full load.
