The Cosel PBA100F-15-N is an enclosed AC/DC power supply designed for ITE (Commercial) applications. It delivers 100W of power with a single 15V output at 7A. The unit accepts a universal input voltage range of 85 to 264 VAC, making it suitable for global use.
Key electrical specifications include a typical efficiency of 88% at 200V AC and 86% at 100V AC. It offers robust protection features such as overcurrent protection (activating above 105% of rated current) and overvoltage protection (minimum 15.75V). The power supply also features a hold-up time of 20ms and a start-up time of 200ms under typical conditions.
Designed for chassis mounting, the PBA100F-15-N meets various safety and compliance standards, including CE marking, UL60950-1, and EN62368-1. It also complies with EMI standards like FCC-B and CISPR22-B, and EMS standards including EN61000-6-2. The unit includes a 5-year warranty.
This power supply is suitable for applications requiring a reliable and efficient enclosed AC-DC conversion solution. Its universal input and compliance with international standards facilitate integration into diverse systems.
85-264 VAC or 110-370 VDC.
15V at 7A, 100W.
Chassis mount, enclosed.
86% typical at 100VAC, 88% typical at 200VAC.
Overcurrent protection >105% and overvoltage protection 15.75V minimum.
3000VAC between input and output, 2000VAC input to FG, 500VAC output to FG.
5 years.
