The Cosel PBA100F-12-N is an enclosed AC/DC power supply unit delivering 100W of power with a 12V DC output. It is designed for universal input, accepting voltages from 85 to 264 VAC, making it suitable for global applications. This model features a chassis mount for easy integration into systems.
Key electrical specifications include a maximum output current of 8.5A and a line regulation of 96mV maximum. The unit offers overcurrent and overvoltage protection, with overcurrent protection activating at 105% of rated current and recovering automatically. Isolation is rated at 3000 VAC for input-to-output and 2000 VAC for input-to-FG.
Compliance includes CE, cURus, and TUV approvals. The power supply is designed for ITE (Commercial) applications and operates efficiently with a typical efficiency of 74% at 200V input. It also complies with harmonic attenuator standards (IEC61000-3-2).
This power supply is suitable for various industrial and commercial equipment requiring a reliable and regulated DC power source. Its enclosed, chassis-mount design facilitates robust system integration.
The input voltage range is 85-264VAC (110-370VDC) at 50/60Hz.
The output is 12V at 8.5A, providing 100W of output power.
The typical efficiency is 74% at both ACIN 100V and ACIN 200V.
It has overcurrent protection that operates above 105% of rated current with automatic recovery, and overvoltage protection in the range of 15.0-18.0V.
The isolation voltage between input and output is 3000VAC for 1 minute.
The output voltage can be adjusted from 10.0V to 13.2V.
The mounting type is chassis mount with an enclosed package.
