| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Halogen Free | |
| Height | |
| Input Current (Full Load) | |
| Input Current (No Load) | |
| Input Voltage Max | |
| Input Voltage Min | |
| Isolation Voltage | |
| Lead Spacing | |
| Lead Style | |
| Length | |
| MTBF | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Width |
The Delta Electronics PB01D1215A is a miniature isolated DC DC converter in a 5-SIP package. It delivers a dual ±15V output at 34mA per output with a total power rating of 1W. The device accepts an input voltage range of 10.8V to 13.2V (12V nominal) and provides 1000VDC input-to-output isolation.
Typical efficiency is 79% at full load with a full load input current of 258mA and no-load input current of 7mA. The converter includes short circuit protection (SCP) and achieves a minimum MTBF of 2 MHours. Operating temperature range is -40°C to +85°C.
The PB01D1215A uses a through-hole mounting style in a 5-SIP module measuring 19.6mm x 6.0mm x 10.2mm. It is RoHS3 compliant and designed for medical applications.
The PB01D1215A provides dual ±15V output.
Each output can deliver up to 34mA.
The converter comes in a 5-SIP through-hole module.
It operates from -40°C to +85°C.
Yes, it is RoHS3 compliant.
