PB-0927PQ The HITPOINT PB-0927PQ is a magnetic buzzer with a 2731 Hz oscillation frequency and a sound pressure level of 85 dB. It operates within a voltage range of 4.5 to 5.5 Vp-p.
Mfr Part #:

PB-0927PQ

Available from 1 distributors
Mfr Name: Hitpoint
Hitpoint
The HITPOINT PB-0927PQ is a magnetic buzzer with a 2731 Hz oscillation frequency and a sound pressure level of 85 dB. It operates within a voltage range of 4.5 to 5.5 Vp-p.
✓ Total Stock: 445 pcs
$ Price Range: $0.99

PB-0927PQ Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
445 pcs
On Request
445 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PB-0927PQ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Coil Resistance
Color
Current Consumption
Housing Material
Operating Temperature
Rated Voltage
SVHC Present
Sound Pressure Level (SPL)
Storage Temperature
Weight
View Similar Products (0)

PB-0927PQ Description

Short technical summary and product information.

The HITPOINT PB-0927PQ is a magnetic buzzer designed for audible signaling applications. It features an oscillation frequency of 2731 Hz and a rated voltage of 5 Vp-p, with an operating voltage range of 4.5 to 5.5 Vp-p.



This buzzer offers a minimum sound pressure level of 85 dB at 10 cm, ensuring audibility in various environments. The current consumption is a maximum of 75 mA at the rated voltage. The coil resistance is specified as 25 ± 4 Ω.



Constructed with a PPO plastic resin housing and tin-plated brass pins, the PB-0927PQ is built for durability. It has a weight of 0.8 grams and comes in a black color. The operating temperature range is -20 °C to +70 °C, and the storage temperature range is -30 °C to +80 °C.



Soldering conditions include wave soldering at 260 ± 5 °C for within 5 seconds and manual soldering at 350 ± 20 °C for within 5 seconds.

PB-0927PQ Quick Information

Product Type: Magnetic Buzzer
Series: PB
Canonical Name: HITPOINT PB-0927PQ Magnetic Buzzer
Subcategory: Magnetic Buzzer

PB-0927PQ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PB-0927PQ Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

PB-0927PQ Features

  • Magnetic buzzer with 2731 Hz oscillation frequency.
  • Operates at 4.5 to 5.5 Vp-p.
  • Provides 85 dB minimum sound pressure level.
  • Durable PPO plastic resin housing.
  • Wide operating temperature range.

PB-0927PQ Applications

  • Used for audible alarms.
  • Suitable for status indicators.
  • Incorporated into warning systems.
  • Applied in electronic devices.

PB-0927PQ FAQs

6 frequently asked questions generated from this part’s specifications.
What is the oscillation frequency of the PB-0927PQ buzzer?

The oscillation frequency is 2731 Hz.

What is the operating voltage range for the PB-0927PQ?

The operating voltage range is 4.5 to 5.5 Vp-p.

What is the minimum sound pressure level of the PB-0927PQ?

The minimum sound pressure level is 85 dB at 10 cm.

What is the coil resistance of the PB-0927PQ?

The coil resistance is 25 ± 4 Ω.

What are the operating and storage temperature ranges for the PB-0927PQ?

The operating temperature is -20 to +70 °C, and the storage temperature is -30 to +80 °C.

What material is the housing of the PB-0927PQ made from?

The housing is made from PPO Plastic Resin.
