PAT0603E1210BST1 The Vishay Dale PAT0603E1210BST1 is a Thin Film Chip Resistor with a resistance of 121 Ohms and a tolerance of ±0.1%. It has a power rating of 0.15W and is housed in a 0603 package.
Mfr Part #:

PAT0603E1210BST1

Available from 1 distributors
Mfr Name: Vishay
Vishay
The Vishay Dale PAT0603E1210BST1 is a Thin Film Chip Resistor with a resistance of 121 Ohms and a tolerance of ±0.1%. It has a power rating of 0.15W and is housed in a 0603 package.
✓ Total Stock: 995 pcs
$ Price Range: $0.02

PAT0603E1210BST1 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
ADI/AAR OEM Supply ✓
Non-Authorised Inventory information
995 pcs
On Request
995 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

PAT0603E1210BST1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Composition
Features
Height
Length
Number of Terminations
Operating Temperature
Power (Watts)
Ratings
Resistance
Supplier Device Package
Tape & Reel
Temperature Coefficient
Tolerance
Width
View Similar Products (0)

PAT0603E1210BST1 Description

Short technical summary and product information.

This Vishay Dale PAT0603E1210BST1 is a surface mount chip resistor designed for various electronic applications. It features a resistance value of 121 Ohms with a tight tolerance of ±0.1%, ensuring precise circuit performance.



The resistor has a power rating of 0.15W and is constructed using Thin Film technology. It operates within a temperature range of -55°C to 155°C and boasts a temperature coefficient of ±25ppm/°C.



Key features include its Anti-Sulfur, Automotive AEC-Q200, and Moisture Resistant properties, making it suitable for demanding environments. The component is supplied in a 0603 (1608 Metric) package, designed for surface mounting.



Additional specifications include a height of 0.46mm, length of 1.63mm, and width of 0.81mm. It has 2 terminations and is rated AEC-Q200.

PAT0603E1210BST1 Quick Information

Product Type: Chip Resistor - Surface Mount
Series: PAT
Canonical Name: Vishay Dale PAT0603E1210BST1 Thin Film Chip Resistor, 121 Ohm, 0.1% Tolerance, 0.15W, 0603 Package
Subcategory: Surface Mount

PAT0603E1210BST1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

PAT0603E1210BST1 Estimated Pricing

Qty Low High
1+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

PAT0603E1210BST1 Features

  • 121 Ohm resistance with 0.1% tolerance.
  • 0.15W power rating in a 0603 package.
  • Thin Film construction for stability.
  • AEC-Q200 automotive qualified.
  • Moisture resistant and anti-sulfur features.

PAT0603E1210BST1 Applications

  • Suitable for automotive applications.
  • Ideal for circuits requiring precision.
  • Used in harsh environmental conditions.
  • Surface mount assembly compatible.

PAT0603E1210BST1 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance value of the PAT0603E1210BST1 resistor?

The resistance value is 121 Ohms.

What is the tolerance of the Vishay Dale PAT0603E1210BST1?

The tolerance is ±0.1%.

What is the power rating for the PAT0603E1210BST1 chip resistor?

The power rating is 0.15W.

What is the operating temperature range for this resistor?

The operating temperature range is -55°C to 155°C.

What package size is the PAT0603E1210BST1 resistor?

The resistor is in a 0603 (1608 Metric) package.

Does this resistor meet automotive standards?

Yes, it is Automotive AEC-Q200 qualified and features Anti-Sulfur and Moisture Resistant properties.
