| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Dimensions | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The PAA25-13 from TT Electronics/BI is an encapsulated AC/DC power supply designed for reliable power conversion. It delivers a 15V output voltage with a maximum current of 1.67A, providing a total output power of 25W. The unit accepts a wide universal input voltage range of 90-305VAC, making it suitable for global applications.
Key electrical specifications include an efficiency of up to 88% and an I/O isolation of 4000VAC. The power supply operates within an ambient temperature range of -40°C to +70°C, with derating applied at higher temperatures. Its compact dimensions of 52.5mm x 27.5mm x 23.5mm allow for integration into space-constrained designs.
This power supply is suitable for applications in household appliances and ITE (Commercial) environments. It holds safety approvals from CB, CE, and cURus, and complies with UL/IEC/EN 62368-1, IEC/EN 60950, TUV IEC/EN60335-1, and TUV IEC/EN 61558-2-16 standards. The PAA25-13 is designed for through-hole mounting.
The input voltage range is 90-305VAC at 47-440Hz.
The output voltage is 15V at 1.67A for 25W total power.
The operating temperature range is -40°C to +70°C with derating.
The package is a 4-DIP through-hole module with dimensions 27.5x52.5x31.5mm.
The efficiency is 88% typical.
It is approved to UL/IEC/EN 62368-1, IEC/EN 60950, TUV IEC/EN60335-1, and TUV IEC/EN 61558-2-16.
No, it is EMC compliant without external components.
