The P6KE36CA is a transient voltage suppressor (TVS) diode manufactured by Taiwan Semiconductor, designed for robust circuit protection. This bidirectional device features a peak pulse power dissipation capability of 600W on a 10/1000μs waveform, making it suitable for absorbing transient voltage events.
Key electrical characteristics include a reverse standoff voltage of 30.8V and a maximum clamping voltage of 49.9V at the peak pulse current. The breakdown voltage ranges from 34.2V to 37.8V. The diode operates within a junction and storage temperature range of -55°C to +150°C.
Packaged in a DO-204AC (DO-15) case, the P6KE36CA is designed for through-hole mounting. Its typical thermal resistance from junction to ambient is 75°C/W. The device also offers a steady-state power dissipation of 5W at 75°C.
This TVS diode is compliant with RoHS3 standards and is suitable for applications requiring protection against voltage transients.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The P6KE36CA has a peak pulse power dissipation of 600W on a 10/1000μs waveform.
The reverse standoff voltage (Vrwm) for the P6KE36CA is 30.8V.
The maximum clamping voltage (Vc Max) for the P6KE36CA is 49.9V at the peak pulse current.
The breakdown voltage (VBR) for the P6KE36CA ranges from a minimum of 34.2V to a maximum of 37.8V.
The P6KE36CA is supplied in a DO-204AC (DO-15) package.
The P6KE36CA is RoHS3 Compliant.
