| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| SVHC Present | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Width |
This Daburn Electronics P52-12 is an enclosed AC-DC power module designed for commercial ITE applications. It accepts a 105-125 VAC input voltage and provides three regulated DC outputs: +5VDC, +12VDC, and -12VDC. The module is rated for output currents of 250mA for the 5V output and 120mA for each of the +/-12V outputs.
The P52-12 features through-hole mounting and a 7-DIP Module package, making it suitable for board-level integration. Key electrical specifications include a line regulation of 0.02% and a load regulation of 0.1%. It also includes short circuit protection (SCP).
Environmental specifications include an operating temperature range of -25°C to 71°C. The module is approved by CE and cURus agencies. Its dimensions are 88.9mm x 63.5mm x 39.6mm.
The Daburn P52-12 provides three output voltages: +5VDC, +12VDC, and -12VDC.
The P52-12 accepts an input voltage range of 105 to 125 VAC.
The operating temperature range for the P52-12 is -25°C to 71°C.
The P52-12 uses through-hole mounting.
Yes, the P52-12 features short circuit protection (SCP).
