This Polytron P34 series AC/DC converter module provides a regulated -15V DC output at 200mA. It operates from a 105-125 Vac input voltage at 50-60 Hz and features line and load regulation of ±0.2%. The module is designed for through-hole mounting and comes in a 7-DIP module package.
Key features include short circuit protection and an isolation resistance of 50 MOhms. The operating temperature range is -25°C to +71°C, with a storage temperature range of -25°C to +85°C. Cooling is achieved through free air convection. The dimensions are 88.9mm x 63.5mm x 31.8mm.
This converter is suitable for ITE (Commercial) applications and carries CE, cURus, and UL approval. It is designed for PC card or chassis mounting, offering flexibility in integration.
The input voltage range is 105-125 Vac at 50-60 Hz.
Output voltage is -15 Vdc with a maximum output current of 200 mA.
The P34 has two outputs.
Operating temperature range is -25°C to 71°C.
It comes in a 7-DIP module with 5 leads and through-hole mounting.
It includes short circuit protection (SCP).
Dimensions are 88.9mm x 63.5mm x 31.8mm (3.50" x 2.50" x 1.25").
