| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Package / Case | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The Daburn Electronics P33-48S is a linear encapsulated power module designed for AC to DC conversion. It features a 48VDC output voltage and can supply up to 100mA of current.
This converter operates with an input voltage range of 105 to 125 VAC. Key electrical specifications include line and load regulation of 0.2%, and a temperature coefficient of ±0.02%/°C typical. It also offers 50MOhms isolation resistance and short circuit protection.
The P33-48S is designed for Through Hole mounting and comes in a 7-DIP Module, 5 Leads package. The operating temperature range is -25°C to 71°C, with a storage temperature range of -25°C to 85°C. Cooling is achieved through free air convection.
This component is suitable for ITE (Commercial) applications and carries CE, cURus approval agency certifications.
The P33-48S has an output voltage of 48VDC.
The P33-48S can supply a maximum output current of 100mA.
The input voltage range for the P33-48S is 105 to 125 VAC.
The P33-48S operates within a temperature range of -25°C to 71°C.
The P33-48S is designed for Through Hole mounting.
Yes, the P33-48S includes short circuit protection.
