| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Protection | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Voltage Range | |
| Width |
The Polytron P33-24T is a linear encapsulated AC DC power module designed for ITE (Commercial) applications. It offers a regulated -24Vdc output with a current rating of 100mA. The unit is designed for chassis mounting and includes essential features like short circuit protection for enhanced reliability.
This converter operates within a temperature range of -25°C to +71°C, with an optional extended range available. It accepts a nominal input voltage of 115 Vac at 50-60 Hz, with a specified input voltage range of 105-125 Vac. The module provides line and load regulation between 0.02% and 0.2%, and a voltage accuracy of ±1.0% at full load. Isolation resistance is rated at 50MOhms.
Physical dimensions include a length of 104.1mm (4.10"), a width of 63.5mm (2.50"), and a height of 31.8mm (1.25"). The P33-24T is approved by CE and cURus agencies. It is suitable for applications requiring a stable, regulated negative DC voltage from an AC input.
-24Vdc
100 mA
Chassis Mount
-25°C to +71°C
Yes, it features Short Circuit Protection.
104.1mm (L) x 63.5mm (W) x 31.8mm (H)
