The Polytron P33-12SW is a linear encapsulated power module designed for AC to DC conversion. It operates with an input voltage range of 105 to 125 VAC at 50-60 Hz, providing a regulated 12VDC output at 120mA.
Key electrical specifications include line regulation of ±0.2% and load regulation of ±0.2%. The device offers short circuit protection (SCP) and a temperature coefficient of ±0.02%/°C typical. Isolation resistance is rated at 50MOhms.
This converter is housed in a 7-DIP Module, 5 Leads package and is designed for Through Hole mounting. It operates within an ambient temperature range of -40°C to +85°C and is cooled by free air convection. The physical dimensions are 88.9mm in length, 63.5mm in width, and 22.4mm in height.
Compliance includes RoHS3, MSL 1, and REACH Unaffected status. The P33-12SW is suitable for ITE (Commercial) applications and carries CE, cURus, and UL approval agency certifications.
The P33-12SW provides a regulated 12VDC output at 120mA.
The input voltage range for this converter is 105 to 125 VAC.
The line regulation is ±0.2% and the load regulation is ±0.2%.
The operating temperature range is -40°C to +85°C.
The P33-12SW uses Through Hole mounting.
