| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
32,618 pcs
|
32618 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Efficiency | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Operating Temperature | |
| Output Current | |
| Output Type | |
| Output Voltage | |
| Power | |
| Storage Temperature | |
| Tape & Reel |
The PEAK P10LU-0505ELF is a compact 2 Watt DC/DC converter from the P10LU-xxxxELF series. It features a single unregulated output with a nominal voltage of 5 VDC and a maximum output current of 400 mA.
This converter operates within an input voltage range of 4.5 to 5.5 VDC and provides a high isolation voltage of 3000 VDC. Key electrical specifications include an efficiency of 81% at full load and a maximum ripple and noise of 75 mV pk-pk.
Designed for reliability, it includes short-term short circuit protection and has an MTBF of greater than 1.121 Mhrs at 25°C. The operating temperature range is -40 to +100 °C. The component is housed in a SIP case made of black plastic, flame-retardant and heat-resistant (UL 94V0) material, with dimensions of 19.5 x 6.0 x 10.0 mm.
It is delivered in a tube containing 20 pieces.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The P10LU-0505ELF has a power rating of 2 Watts.
The P10LU-0505ELF provides a 5 VDC output voltage with a maximum output current of 400 mA.
The P10LU-0505ELF has a minimum isolation voltage of 3000 VDC.
The operating temperature range for the P10LU-0505ELF is -40 to +100 °C.
The case dimensions of the P10LU-0505ELF are 19.5 x 6.0 x 10.0 mm.
