L78M05CDT-TR
ST
The ST L78M05CDT-TR is a linear voltage regulator in a TO-252-2 package. It features RoHS3 compliance and an MSL of 1.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200,000 pcs
|
200000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| SVHC Present |
The STMicroelectronics P0102MN5AA4 is a sensitive gate Silicon Controlled Rectifier (SCR) designed for various electronic applications. It features a maximum off-state voltage of 600V and a maximum on-state current of 800mA RMS.
This SCR has a low gate trigger voltage of 800mV and a low gate trigger current of 200µA, making it sensitive to gate signals. The on-state voltage drop is a maximum of 1.95V, and the holding current is a maximum of 5mA. The off-state current is minimal, at 10µA maximum.
Packaged in a surface-mount SOT-223 package, the P0102MN5AA4 is suitable for automated assembly processes. It is supplied on tape and reel for high-volume manufacturing. The non-repetitive surge current is rated at 7A and 8A for 50Hz and 60Hz respectively.
This component is ideal for applications requiring efficient power control and switching. Its sensitive gate characteristic allows for easy triggering with low-power control signals.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum off-state voltage is 600V.
The maximum RMS on-state current is 800mA.
The P0102MN5AA4 SCR is in a SOT-223 surface mount package.
The maximum gate trigger voltage is 800mV.
The maximum gate trigger current is 200µA.
