| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Dimensions | |
| For Use With | |
| Mounting Type | |
| Operating Temperature | |
| Reset Time | |
| SVHC Present | |
| Weight | |
| Working Voltage |
The ABLE Power Products OVCD-230-HW is an Over Voltage and Under Voltage Cut-Off device designed to protect sensitive electronic components in fixtures. It extends the life of drivers and controls by eliminating temporary over and under voltages.
This protector automatically shuts off power when the nominal voltage increases or decreases by 40V. It features Safe Restore™ technology, which allows the unit to auto-reset instantly when the voltage returns to normal operating levels. The device has a nominal operating voltage of 230 VAC and a working current rating of 7A, with a rated frequency range of 47-63Hz.
Key specifications include a 90-second reset time and a 90-second power-on delay. The OVCD-230-HW has an IP rating of 10 and is designed for tab mounting. It connects using 18-16 AWG multi-strand soft wire and operates within an environment temperature range of -40°C to +85°C. The dimensions are 38mm x 66mm, with an approximate weight of 55g.
For volume purchases, voltage settings can be customized to specific requirements. This device is suitable for applications where stable voltage is critical to prevent damage to electronic components.
230 VAC
It uses a tab mount configuration.
-40°C to +85°C
It triggers at 270 VAC for overvoltage and 190 VAC for undervoltage.
Both the reset time and power-on delay are 90 seconds.
A green LED indicates input power on, and a red LED indicates over/under voltage conditions.
It supports 18-16 AWG multi-strand soft wire connections.
