| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Dimensions | |
| For Use With | |
| Mounting Type | |
| Operating Temperature | |
| Operating Voltage | |
| Reset Time | |
| Weight |
The ABLE Power Products OVCD-120-HW is an Over Voltage and Under Voltage Cut-Off device with Safe Restore technology, designed to protect sensitive electronic components in fixtures from damaging voltage fluctuations. It automatically shuts off power when the nominal voltage decreases by 40V or increases by 40V, and auto-resets when the voltage returns to normal.
Key electrical specifications include a working voltage of 230 VAC and a working current of 7A, with a rated frequency of 47-63Hz. The device has an over-voltage trip point of 270V and an under-voltage trip point of 190V. It features a 90-second reset time and a 90-second power-on delay. The operating temperature range is -40°C to +85°C.
Mechanically, the OVCD-120-HW is a tab mount device with dimensions of 38mm x 66mm and a weight of approximately 55g. It uses 18-16 AWG multi-strand soft wire for connections and has an IP rating of 10. The device operates at altitudes below 2000m.
This protector is ideal for applications where stable voltage is critical for the longevity of electronic components, such as in lighting fixtures. Its auto-reset capability and voltage protection features make it a reliable solution for preventing damage from temporary over and under voltage conditions.
The operating voltage is 230 VAC.
The over-voltage trip point is 270V.
The under-voltage trip point is 190V.
The reset time is 90 seconds.
The operating temperature range is -40°C to +85°C.
It uses a tab mount.
