| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
130 pcs
|
130 pcs | On Request | 1 | On Request | On Request | 24+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Lens Size | |
| Mounting Type | |
| Pixel Size | |
| Resolution | |
| Sensitivity | |
| Technology |
The OmniVision OV3620 is a high-performance 3.2 megapixel CMOS image sensor designed for digital still and video camera products. It incorporates a 2048 x 1536 (QXGA) image array and a 10-bit A/D converter, capable of operating at up to 7.5 frames per second in full resolution mode.
Proprietary OmniPixel® technology enables advanced algorithms to cancel Fixed Pattern Noise (FPN), eliminate smearing, and reduce blooming, resulting in crystal-clear photographs with true colors, even in low-light conditions. The sensor offers flexible control of timing and operation, providing engineers with design freedom.
Key specifications include a 1/2" lens size, 3.18 µm pixel size, and a sensitivity of > 1 V/Lux-sec. The OV3620 supports progressive scan mode and outputs 10-bit digital RGB Raw data. It operates on a 3.3VDC / 1.8VDC power supply with active power consumption below 40 mA.
Applications for the OV3620 include digital still cameras, PC cameras, video conferencing, machine vision, security cameras, and biometrics. The device is available in a lead-free CLCC-48 package.
The OV3620 image sensor has a resolution of 3.2 megapixels.
The maximum array size for the OV3620 is QXGA, which is 2048 x 1536 pixels.
The OV3620 provides 10-bit digital RGB Raw data.
The OV3620 operates on a 3.3VDC or 1.8VDC power supply.
The sensitivity of the OV3620 is greater than 1 V/Lux-sec.
The S/N Ratio of the OV3620 is 46 dB.
The pixel size of the OV3620 is 3.18 µm x 3.18 µm.
