| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Forward Voltage | |
| Height | |
| Length | |
| Mounting Style | |
| Mounting Type | |
| Output Type | |
| Power Dissipation | |
| Reverse Voltage | |
| Sensing Distance | |
| Sensing Method | |
| Wavelength | |
| Width |
The OPB700ALZ from TT Electronics / Optek is a reflective optical sensor utilizing a phototransistor output. It is designed for applications requiring detection of reflected light.
Key electrical specifications include a maximum collector-emitter breakdown voltage of 24V and a typical forward voltage of 1.7V. The sensor operates with a maximum forward current of 100mA and has a maximum collector current of 2.5mA. Its sensing distance is specified at 0.200 inches (5.08mm).
This sensor operates within a temperature range of -40°C to 100°C. It is housed in a module with pre-wired leads and is designed for chassis mounting. The device emits infrared light with a wavelength of 890nm.
The OPB700ALZ is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1. Its dimensions include a width of 2.54mm, length of 15.24mm, and height of 25.4mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.50 | $1.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Phototransistor
5.08mm
24V
-40°C to 100°C
Module, Pre-Wired
100mA
890nm
