| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,000 pcs
|
3000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| Drive Voltage (Max Rds On, Min Rds On) | |
| FET Type | |
| Gate Charge (Qg) (Max) @ Vgs | |
| Halogen Free | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation (Max) | |
| Rds On (Max) @ Id, Vgs | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Vgs (Max) | |
| Vgs(th) (Max) @ Id |
The NVMYS012N10MCLTWG is a single N-Channel MOSFET manufactured by On Semiconductor. It is designed for power applications, featuring a drain-to-source voltage (Vdss) of 100V and a maximum continuous drain current (Id) of 52A at 25°C case temperature. The MOSFET exhibits a low on-resistance (Rds(on)) of 12.2mOhm at 14A and 10V gate-source voltage, minimizing conduction losses.
This device operates within a wide temperature range of -55°C to 175°C (TJ). It is available in a compact LFPAK4 (5x6 mm) surface mount package, suitable for space-constrained designs. The MOSFET is AEC-Q101 qualified and PPAP capable, indicating its suitability for automotive applications. It is also Pb-Free, Halogen Free/BFR Free, and RoHS Compliant.
Key electrical characteristics include a gate threshold voltage (Vgs(th)) of 3V at 77µA, an input capacitance (Ciss) of 1338pF at 50V, and a gate charge (Qg) of 19nC at 10V. The maximum gate-to-source voltage is ±20V. Power dissipation is rated at 72W (Tc) and 3.6W (Ta).
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The drain-to-source voltage (Vdss) is 100V.
The maximum continuous drain current is 52A at 25°C case temperature.
The on-resistance (Rds On) is a maximum of 12.2mOhm at 14A and 10V gate-source voltage.
The operating junction and storage temperature range is -55°C to +175°C.
It is available in the LFPAK4 (5x6 mm) package, which is a surface mount type.
Yes, the device is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
