| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | |
| Frequency | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Supplier Device Package | |
| Transistor Type | |
| Vce Saturation (Max) @ Ib, Ic | |
| Voltage |
The NTE Electronics NTE96 is a single NPN bipolar junction transistor (BJT) with a maximum voltage rating of 100V and a continuous collector current of 7A. It offers a power dissipation of 60W and a transition frequency of 30MHz.
This transistor features a DC current gain (hFE) of at least 60 at 2A and 2V. The saturation voltage (Vce(sat)) is a maximum of 1.2V at 700mA and 7A. It is designed for stud mount applications and comes in a TO-210AA, TO-59-4, Stud package.
The operating temperature range for the NTE96 is -65°C to 200°C (TJ), making it suitable for demanding thermal environments. It is RoHS3 compliant, has an MSL of 1, and is REACH unaffected.
This component is ideal for power switching and amplification circuits requiring robust performance under significant voltage and current loads.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The NTE96 transistor has a maximum operating voltage of 100V.
The NTE96 transistor can handle a maximum continuous current of 7A.
The NTE96 transistor has a power dissipation rating of 60W.
The operating temperature range for the NTE96 transistor is -65°C to 200°C (TJ).
The NTE96 transistor is supplied in a TO-210AA, TO-59-4, Stud package.
The DC current gain (hFE) of the NTE96 transistor is a minimum of 60 at 2A and 2V.
The saturation voltage (Vce Sat) for the NTE96 transistor is a maximum of 1.2V at 700mA and 7A.
