| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Diode Configuration | |
| Mounting Type | |
| Operating Temperature | |
| Reverse Recovery Time (trr) | |
| Speed | |
| Supplier Device Package | |
| Technology | |
| Voltage |
The NTE6200 is a fast recovery rectifier diode array from NTE Electronics, featuring two diodes in a common cathode configuration. It is designed for high-speed switching applications requiring low reverse recovery losses.
Key electrical characteristics include a typical forward voltage of 1.4V at 15A, a reverse recovery time of 200ns, and a maximum reverse leakage current of 5mA at 200V. The device operates over a wide temperature range from -65°C to 150°C.
The diode array is housed in a through-hole TO-3 package (TO-204AA equivalent), which offers robust mechanical mounting and efficient heat dissipation. It is suitable for use in power supplies, inverters, and motor control circuits where fast switching and common cathode configuration are needed.
Compliance data indicates RoHS3, REACH unaffected, and MSL 1 (unverified). Designers should verify with the manufacturer for current compliance status.
| Qty | Low | High |
|---|---|---|
| 1+ | $12.24 | $12.24 |
| 25+ | $12.12 | $12.12 |
| 100+ | $12.00 | $12.00 |
| 500+ | $11.93 | $11.93 |
| 999+ | $11.87 | $11.87 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward voltage is 1.4V at a forward current of 15A.
The reverse recovery time is 200ns.
The operating temperature range is -65°C to 150°C.
It is a 1 pair common cathode configuration.
It is available in a through-hole TO-3 package (TO-204AA case).
The maximum reverse leakage current is 5mA at 200V.
RoHS3 compliance is indicated but unverified; confirm with manufacturer.
