| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Diode Configuration | |
| Mounting Type | |
| Operating Temperature | |
| Speed | |
| Supplier Device Package | |
| Technology | |
| Voltage |
The NTE6085 from NTE Electronics is a dual Schottky diode array containing two independent Schottky barrier diodes in a single TO-220-3 through-hole package. It is designed for high-efficiency rectification and fast switching applications.
Key electrical specifications include a typical forward voltage of 570 mV at 7.5 A forward current, fast recovery speed of less than 500 ns for currents above 200 mA, and an operating temperature range of -65°C to 150°C. The part is rated for a reverse voltage of 45 V and an average rectified current of 16 A.
The TO-220-3 package provides excellent thermal performance and is suitable for through-hole mounting on PCBs. The dual diode configuration allows for compact designs in power supplies, converters, and freewheeling circuits.
The typical forward voltage is 570 mV at a forward current of 7.5 A.
The NTE6085 comes in a TO-220-3 through-hole package.
It contains two independent Schottky diodes.
The reverse voltage rating is 45 V, based on the reverse leakage test condition.
The average rectified current is 16 A, as indicated in the part description.
It is a fast recovery diode with recovery time less than 500 ns for currents above 200 mA.
It uses Schottky barrier technology.
