| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,000 pcs
|
2000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Conflict Minerals | |
| ESR (Equivalent Series Resistance) | |
| Mounting Type | |
| Operating Temperature | |
| SVHC Present | |
| Tolerance | |
| Type |
This NIC Components NTC-T106K10TRAF is a molded tantalum capacitor designed for general-purpose applications. It offers a capacitance of 10 µF with a tolerance of ±10% and a rated voltage of 10 V.
The capacitor operates within a temperature range of -55°C to 125°C and has an equivalent series resistance (ESR) of 3.2 Ohms at 100kHz. Its expected lifetime is 2000 hours at 85°C.
Packaged in a 1206 (3216 Metric) case, this surface mount component measures 0.126" L x 0.063" W (3.20mm x 1.60mm) with a maximum seated height of 0.071" (1.80mm). It is supplied on tape and reel.
Environmental compliance includes RoHS3 compliance, REACH unaffected status, and Moisture Sensitivity Level 1.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.33 | $0.33 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The capacitance is 10 µF with a rated voltage of 10 V.
The tolerance is ±10%.
The typical ESR is 3.2 Ω at 100 kHz.
It is available in a 1206 (3216 metric) surface mount package.
The operating temperature range is -55°C to 125°C.
The lifetime is 2000 hours at 85°C.
The mounting type is surface mount.
