NT2016SB The NDK America, Inc. NT2016SB is a Temperature Compensated Crystal Oscillator (TCXO) with a nominal frequency range of 12 to 52 MHz. It supports a supply voltage from 1.7 V to 3.3 V.
Mfr Part #:

NT2016SB

Available from 1 distributors
Mfr Name: NDK America, Inc.
NDK America, Inc.
The NDK America, Inc. NT2016SB is a Temperature Compensated Crystal Oscillator (TCXO) with a nominal frequency range of 12 to 52 MHz. It supports a supply voltage from 1.7 V to 3.3 V.
✓ Total Stock: 2,000 pcs

NT2016SB Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Chanetech ✓
Non-Authorised Inventory information
2,000 pcs
On Request
2000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

NT2016SB Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Height
Mounting Type
Output Voltage
Weight
View Similar Products (0)

NT2016SB Description

Short technical summary and product information.

The NT2016SB from NDK America, Inc. is a Temperature Compensated Crystal Oscillator (TCXO) designed for applications requiring high frequency stability over temperature variations. It features a nominal frequency range of 12 to 52 MHz and operates with a low supply voltage, supporting DC +1.7 V to +3.3 V, with a standard specification of +1.8 V.



This TCXO offers excellent frequency stability, with a frequency/temperature characteristic of ±2.0 ppm over the operating temperature range of -30 °C to +85 °C. It also includes a stand-by function and low power consumption, making it suitable for mobile and wireless applications.



The NT2016SB is an ultra-compact, lightweight, surface-mount crystal oscillator with dimensions of a maximum 0.8 mm height, 0.0022 cm3 volume, and 0.008 g weight. It is lead-free and meets the requirements for reflow soldering, making it compatible with modern manufacturing processes.

NT2016SB Quick Information

Product Type: Temperature Compensated Crystal Oscillator
Series: NT2016SB
Canonical Name: Temperature Compensated Crystal Oscillator
Subcategory: Temperature Compensated Crystal Oscillator (TCXO)

NT2016SB Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Lead-free

NT2016SB Features

  • Highly stable frequency over temperature.
  • Supports low power supply voltage.
  • Ultra-compact and lightweight design.
  • Surface-mount for reflow soldering.
  • Includes stand-by function.

NT2016SB Applications

  • Used in wireless communication modules.
  • Ideal for GPS and timing applications.
  • Suitable for IoT and portable devices.
  • Applicable in industrial temperature ranges.

NT2016SB FAQs

7 frequently asked questions generated from this part’s specifications.
What is the frequency range of the NT2016SB?

12 to 52 MHz.

What is the supply voltage range?

1.7 V to 3.3 V.

What is the operating temperature range?

-30 °C to +85 °C.

What is the frequency stability over temperature?

±2 ppm.

What is the output waveform and voltage?

Clipped sine wave, 0.8 Vp-p.

What is the current consumption?

2.5 mA max during operation, 2 µA typical in standby.

What is the mounting type?

Surface mount.
