| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
27,000 pcs
|
27000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
6,000 pcs
|
6000 pcs | On Request | 1 | On Request | On Request | 16+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Automotive Grade | |
| Current | |
| Data Rate (Max) | |
| Frequency | |
| GPIO | |
| Memory Size | |
| Modulation | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Protocol | |
| RF Family | |
| Sensitivity | |
| Serial Interfaces | |
| Supplier Device Package | |
| Tape & Reel | |
| Type | |
| Voltage |
The NRF51824-QFAA-R from Nordic Semiconductor is an RF Transceiver IC designed for automotive applications, featuring Bluetooth Low Energy connectivity. It supports Bluetooth v4.0 and v4.2 protocols, operating in the 2.4GHz ISM band.
Key electrical specifications include a supply voltage range of 1.9V to 3.6V, a maximum data rate of 2Mbps, and a typical receiver sensitivity of -96dBm. Transmitting current ranges from 4.7mA to 16mA, while receiving current is between 8.7mA and 13.4mA. The device offers an output power of 4dBm and supports GFSK modulation.
This IC is housed in a 48-VFQFN Exposed Pad package, measuring 6x6mm with a height of 0.85mm. It is designed for surface mounting. The operating temperature range is -40°C to 105°C. It includes 256kB Flash memory and 16kB RAM, with 31 GPIO pins available for interfacing.
With its automotive qualification and robust feature set, the NRF51824-QFAA-R is suitable for various wireless communication applications requiring reliable and efficient Bluetooth connectivity.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.43 | $3.43 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage range is 1.9V to 3.6V.
The NRF51824-QFAA-R is supplied in a 48-VFQFN Exposed Pad package.
The operating temperature range is -40°C to 105°C.
The RoHS status is ROHS3 Compliant.
It supports Bluetooth v4.0 and v4.2.
The maximum data rate is 2Mbps.
The typical receiver sensitivity is -96dBm.
