NPIS43D4R7MTRF This NIC Components NPIS43D4R7MTRF is a shielded wire-wound SMD inductor with an inductance of 4.7 μH and a current rating of 1.32A.
Mfr Part #:

NPIS43D4R7MTRF

Available from 1 distributors
Mfr Name: NIC
NIC
This NIC Components NPIS43D4R7MTRF is a shielded wire-wound SMD inductor with an inductance of 4.7 μH and a current rating of 1.32A.
✓ Total Stock: 2,500 pcs
$ Price Range: $0.19

NPIS43D4R7MTRF Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
2,500 pcs
On Request
2500 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

NPIS43D4R7MTRF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Depth
Dimensions
Failure Rate
Height
Inductance
Lead Style
Length
Mounting Type
Tape & Reel
Tolerance
View Similar Products (0)

NPIS43D4R7MTRF Description

Short technical summary and product information.

The NIC Components NPIS43D4R7MTRF is a shielded wire-wound surface mount device (SMD) inductor. It features an inductance value of 4.7 μH with a tolerance of ±20% and a maximum DC current rating of 1.32A.



With a maximum DC resistance of 72mΩ, this inductor is designed for operation within a temperature range of -55°C to +125°C. Its dimensions are 4.8mm in length, 4.8mm in depth, and 3mm in height, making it suitable for compact electronic designs.



The shielded construction results in a low leakage field, and it is compatible with high reflow temperatures. This inductor is suitable for applications such as DC/DC converters.

NPIS43D4R7MTRF Quick Information

Product Type: Shielded Wire-wound SMD Inductor
Series: NPIS43D
Canonical Name: NIC Components NPIS43D4R7MTRF Shielded Wire-wound SMD Inductor
Subcategory: Fixed Inductor

NPIS43D4R7MTRF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

NPIS43D4R7MTRF Estimated Pricing

Qty Low High
1+ $0.19 $0.19

Estimated market price range - modelled values for guidance only, not live distributor offers.

NPIS43D4R7MTRF Features

  • Shielded wire-wound SMD inductor.
  • Inductance: 4.7 μH ±20% tolerance.
  • Maximum DC current: 1.32A.
  • Wide operating temperature range: -55°C to +125°C.
  • Compact dimensions: 4.8 x 4.8 x 3mm.

NPIS43D4R7MTRF Applications

  • Ideal for DC/DC converters.
  • Suitable for power supply circuits.
  • Used in compact electronic modules.
  • Applications requiring low magnetic leakage.

NPIS43D4R7MTRF FAQs

7 frequently asked questions generated from this part’s specifications.
What is the inductance of the NPIS43D4R7MTRF?

The inductance of the NPIS43D4R7MTRF is 4.7 μH.

What is the tolerance for the 4.7 μH inductance?

The tolerance for the 4.7 μH inductance is ±20%.

What is the maximum DC current rating for this inductor?

The maximum DC current rating for this inductor is 1.32A.

What is the maximum DC resistance?

The maximum DC resistance is 72mΩ.

What are the operating temperature limits?

The operating temperature range is from -55°C to +125°C.

What are the physical dimensions of the NPIS43D4R7MTRF?

The dimensions are 4.8mm in length, 4.8mm in depth, and 3mm in height.

Is this inductor shielded?

Yes, this inductor is magnetically shielded.
