NLASB3157MTR2G The NLASB3157MTR2G is a single-pole, double-throw (SPDT) analog switch from On Semiconductor. It features low on-resistance and a wide operating temperature range.
Mfr Part #:

NLASB3157MTR2G

Available from 4 distributors
Mfr Name: On Semiconductor
On Semiconductor
The NLASB3157MTR2G is a single-pole, double-throw (SPDT) analog switch from On Semiconductor. It features low on-resistance and a wide operating temperature range.
✓ Total Stock: 112,037 pcs
$ Price Range: $0.30

NLASB3157MTR2G Available from 4 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
109,828 pcs
On Request
109828 pcs On Request 1 On Request On Request On Request On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
1,669 pcs
On Request
1669 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
534 pcs
On Request
534 pcs On Request 1 On Request On Request 1329+ On Request On Request
Trace Tec ✓
Non-Authorised Inventory information
6 pcs
On Request
6 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

NLASB3157MTR2G Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Bandwidth
Channel
Channel Capacitance (CS(off), CD(off))
Charge Injection
Crosstalk
Current
Halogen Free
Lead Spacing
Mounting Type
Multiplexer
Number of Circuits
On
Operating Temperature
Propagation Delay
Storage Temperature
Supplier Device Package
Supplier Package
Switch Circuit
Switch Time (Ton, Toff) (Max)
Tape & Reel
Voltage
View Similar Products (0)

NLASB3157MTR2G Description

Short technical summary and product information.

The NLASB3157MTR2G is an advanced CMOS analog switch from On Semiconductor, designed for high-speed applications. It offers a low propagation delay of 1.0 ns and a typical on-resistance of 7 Ohms at 4.5V.



This SPDT switch operates over a wide supply voltage range of 1.65V to 5.5V and maintains a low leakage current of 100 nA. The operating temperature range is from -55°C to 125°C, making it suitable for various environmental conditions.



Packaged in a compact 6-WDFN (1.2x1) surface-mount package, the NLASB3157MTR2G is designed for efficient integration into printed circuit boards. It supports applications requiring clock switching, data multiplexing, and video/audio signal routing.



Key electrical characteristics include a bandwidth of 250 MHz, crosstalk of -54dB at 10MHz, and switch times of 5.2ns (Ton) and 3.5ns (Toff). The device also features break-before-make circuitry to prevent inadvertent shorts.

NLASB3157MTR2G Quick Information

Product Type: Analog Switch
Canonical Name: NLASB3157 SPDT Analog Switch
Subcategory: SPDT

NLASB3157MTR2G Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Pb-Free

NLASB3157MTR2G Estimated Pricing

Qty Low High
1+ $0.30 $0.30

Estimated market price range - modelled values for guidance only, not live distributor offers.

NLASB3157MTR2G Features

  • Low typical on-resistance of 7 Ohms.
  • Fast propagation delay of 1.0 ns.
  • Wide operating voltage from 1.65V to 5.5V.
  • Extended temperature range of -55°C to 125°C.
  • Compact 6-WDFN surface-mount package.

NLASB3157MTR2G Applications

  • Suitable for clock switching applications.
  • Ideal for data multiplexing tasks.
  • Can switch standard video signals.
  • Used for audio signal routing.

NLASB3157MTR2G FAQs

6 frequently asked questions generated from this part’s specifications.
What is the typical propagation delay of the NLASB3157MTR2G?

The typical propagation delay is 1.0 nanoseconds.

What is the on resistance of the NLASB3157MTR2G at VCC = 4.5 V?

The typical on resistance is 3 Ohm.

What is the operating voltage range for the NLASB3157MTR2G?

It operates from 1.65 V up to 5.5 V.

What package does the NLASB3157MTR2G come in?

It is packaged in a 6-WFDFN surface-mount package.

What is the operating temperature range for this device?

-55°C to 125°C.

Is the NLASB3157MTR2G compliant with RoHS?

RoHS compliance status is unverified.
